SPECS

NAC 3 Winch Spiderbot
Capacity – 800 lbs
Speed – Up to 13 ft/sec maximum
Travel – Up to 15ft/sec on a 75 ft long overhead track using double H-Beam supported by Rock and Roll Truss.
Rotation – + or – 360 degrees, up to 180 degrees/second
Cable – 3/16 Tech 12 per winch
Power Requirements – 208 VAC 3 phase 100 amps per leg
Safety – If a motor faults, a failsafe brake stops the axis and the estop button applied will stop the rest

Transportation Will all fit on a stake bed truck

NAC Spiderbot
Capacity – 300 lbs
Speed – Up to 13 ft/sec maximum
Travel – Up to 15ft/sec on a 75 ft long overhead track using a single H-Beam supported by Rock and Roll Truss.
Rotation – Continuous in either direction. Up to 1 revolution per second
Cable – 3/16 Tech 12 per winch
Power Requirements – 208 VAC 3 phase 30 amps per leg
Safety – If a motor faults, a failsafe brake stops the axis and the estop button applied will stop the rest

Transportation Will all fit on a stake bed truck
